Ultra Quiet Air Compressor Models



    Contractor Grade Ultra Quiet, Oil-Free (up to 1.0 Hp)

    Contractor Grade 1hp-1.5hp-2.0hp Air CompressorsDownload
    • CAT-12V1P10S (1 Gal, 12 Volt DC, 0.95 CFM @90 PSI, Steel, 56dB noise level)
    • CAT-1P1060S (1 Gal, 0.6 Hp, 1.2 CFM @90 PSI, Steel, 56dB noise level, 110v)
    • CAT-1P1060SP (1 Gal, 0.6 Hp, 1.2 CFM @90 PSI, Easy-to-Read panel, Steel, 56dB noise level, 110v)
    • CAT-2010A (2.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, 60dB noise level, 110v)
    • CAT-4610AC (4.6 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, 60dB noise level, 110v)
    • CAT-4610S (4.6 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel, 60dB noise level, 110v)
    • CAT-8010 (8.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel, Wheels, 60dB noise level, 110v)
    • CAT-8010AD (8.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel, Wheels, Automatic Drain Valve, 60dB noise level, 110v)
    • CAT-8010A (8.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, Wheels, 60dB noise level, 110v)
    • CAT-8010AAD (8.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, Wheels, Automatic Drain Valve, 60dB noise level, 110v)
    • CAT-8010SPC (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, 40dB noise level, 110v)
    • CAT-8010SPCAD (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, Automatic Drain Valve, 40dB noise level, 110v)

    Contractor Economy Quiet Grade, Oil-Free (1.0, 1.3 Hp)

    • CAT-1510 (1.5 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel Tank, 75dB noise level, 110v)
    • CAT-4710W (4.7 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel Tank, 75dB noise level, 110v)
    • CALAIR 20013 (20 Gal, 1.3 Hp, 3.7 CFM @90 PSI, Steel Tank, 85dB noise level, 110v)

    Contractor Grade Ultra Quiet, Oil-Free (1.5 Hp)

    • CAT-20015 (20 Gal, 1.5 Hp, 2.9 CFM @90 PSI, Steel, Wheels, 70dB noise level, 110v)
    • CAT-20015HP (20 Gal, 1.5 Hp, 3.8 CFM @90 PSI, 2-Stage 175 PSI High Pressure, Steel, Wheels, 70dB noise level, 110v)

    Contractor Grade Ultra Quiet, Oil-Free (2.0 Hp)

    Contractor Grade 2hp Air CompressorsDownload
    • CAT-4620AC (4.6 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Aluminum Tank, 70dB noise level, 110v)
    • CAT-4620AC-22060 (4.6 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Aluminum Tank, 70dB noise level, 220v 60hz)
    • CAT-5020W (5.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Wheels, 70dB noise level, 110v)
    • CAT-10020C (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Wheels, 70dB noise level, 110v)
    • CAT-10020CHAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, Automatic Drain Valve with Manual Cleanout Valve, 70dB noise level, 110v)
    • CAT-10020CHAD-22060 (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, Automatic Drain Valve, 70dB noise level, 220v 60hz)
    • CAT-10020SPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020SPCAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-15020C (15.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, Wheels, 70dB noise level, 110v)
    • CAT-15020C-22060 (15.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, Wheels, 70dB noise level, 220v 60hz)
    • CAT-20020 (20.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Wheels, 70dB noise level, 110v)
    • CAT-20020AD (20.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Wheels, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-20020CTR (20.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 70dB noise level, 110v 60hz)
    • CAT-20020CTR-22060 (20.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 70dB noise level, 220v 60hz)
    • CAT-20020CR (20.0 Gal, 2.0 Hp, Continuous Run 100% Duty Cycle, 5.0 CFM @90 PSI, Steel, Wheels, 77dB noise level, 110v)

    Industrial Grade, Long Life Motor, Oil-Free (1.0 Hp; 4000+ Hrs)

    Contractor Grade Stationary Ultra Quiet, Oil-Free (4.0, 6.0 & 6.5 Hp)

    Stationary Air Compressors 2025Download
    • CAT-20040C (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040SM (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, SMART Controller, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040CAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040SMAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040SPCAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)
    • CAT-60040CAD (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-60040SMAD (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20060CAD (20.0 Gal, 6.0 Hp, 14.6 CFM @90 PSI, Steel Horizontal, Automatic Drain Valve, 78dB noise level, 220v 60hz 1-Phase)
    • CAT-60065C (60.0 Gal, 6.5 Hp, 17.0 CFM @90 PSI, Steel ASME Vertical Tank, 85dB noise level, 208v/230v 60hz 3-Phase)
    • CAT-80060C (80.0 Gal, 6.0 Hp, 16.8 CFM @90 PSI, Steel ASME Vertical Tank, 76dB noise level, 208v/230v 60hz 1-Phase)

    CALAIR Continuous Run Industrial Series (Oiled/Belt Driven)

    • CALAIR 60037BD (60.0 Gal, 3.7 Hp, 11.5 CFM @90 PSI, Steel ASME Vertical Tank, 90dB noise level, 208v/230v 60hz 1-Phase)
    • CALAIR 80050BD (80.0 Gal, 5.0 Hp, 15.0 CFM @90 PSI, Steel ASME Vertical Tank, 90dB noise level, 208v/230v 60hz 1-Phase)

    Smart Controller Series, Oil-Free (Desktop/iPhone – Remote On/Off Scheduling and Increase/Decrease Pressure Control)

    SMART Air Compressor Line 2025Download
    • CAT-10020SMHAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, SMART Controller, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-10020SMSPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, SMART Controller, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020DSMAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, SMART Controller, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-10020HDSMADC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-20040SM (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, SMART Controller, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040SMAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSMADC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-60040SMAD (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-60040DSMADC (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)

    80% Air Dryer Series [ISO 8573 Class 4 Dry Air]

    80 Percent Dry Air CompressorsDownload
    • CAT-8010DSPC (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, 40dB noise level, 110v)
    • CAT-8010DSPCAD (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, Automatic Drain Valve, 40dB noise level, 110v)
    • CAT-10020DC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, 70dB noise level, 110v)
    • CAT-10020DCAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-10020DSMAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, SMART Controller, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-10020DC-22060 (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, 70dB noise level, 220v 60hz 1-phase)
    • CAT-10020DCAD-22060 (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Vertical, 80% Air Dryer, Automatic Drain Valve, 70dB noise level, 220v 60hz 1-phase)
    • CAT-10020DSPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020DSPCAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-20040DC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 80% Air Dryer, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DCAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 80% Air Dryer, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSPCAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 80% Air Dryer, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)
    • CAT-60040DCAD (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, 80% Air Dryer, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)

    98% Air Dryer Series [ISO 8573 Class 2 (2.3.1) Clean/Dry Air compliant; PDP -20′ F. to -51′ F.]

    98-Percent-Dry-Air-CompressorsDownload
    • CAT-10020HDCADC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-10020HDCADC-22060 (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Automatic Drain Valve, 70dB noise level, 220v 60hz 1-phase)
    • CAT-10020HDSPCADC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-10020HDSMADC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-20020DCADC (20.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Automatic Drain Valve, 70dB noise level, 110v)
    • CAT-20040DCADC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSMADC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSPCADC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)
    • CAT-60040DCADC (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, 98% Air Dryer – ISO 8573 2.3.1, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-60040DSMADC (60.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel ASME Vertical Tank, 98% Air Dryer – ISO 8573 2.3.1, SMART Controller, Automatic Drain Valve, 75dB noise level, 220v 60hz 1-Phase)
    • CAT-20060DCC (20.0 Gal, 6.0 Hp, 12.0 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, 78dB noise level, 220v 60hz 1-Phase)

    Sound Proof Cabinet Models – Extremely Ultra Quiet

    Sound Proof Cabinet Air CompressorsDownload
    • CAT-8010SPC (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, 40dB noise level, 110v)
    • CAT-8010SPCAD (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, Automatic Drain Valve, 40dB noise level, 110v)
    • CAT-8010DSPC (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, 80% Air Dryer, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, 40dB noise level, 110v)
    • CAT-8010DSPCAD (8.0 Gal, 1.0 Hp Long Life Motor-Pump, 3.0 CFM @90 PSI, 80% Air Dryer, Sound Proof Cabinet, Epoxy-coated Tank, Caster Wheels, Automatic Drain Valve, 40dB noise level, 110v)
    • CAT-10020SPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020SPCAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-10020SMSPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, SMART Controller, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020DSPC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, 58dB noise level, 110v)
    • CAT-10020DSPCAD (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel, 80% Air Dryer, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-10020HDSPCADC (10.0 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Sound Proof Cabinet, Automatic Drain Valve, 58dB noise level, 110v)
    • CAT-20040SPCAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSPCAD (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 80% Air Dryer, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)
    • CAT-20040DSPCADC (20.0 Gal, 4.0 Hp, 10.6 CFM @90 PSI, Steel Horizontal, 98% Air Dryer – ISO 8573 2.3.1, Sound Proof Cabinet, Automatic Drain Valve, 65dB noise level, 220v 60hz 1-Phase)

    Auxiliary Air Tanks

    • AUX02S (2 Gal, Steel, 11 lbs, 19″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • AUX05A (5 Gal, Aluminum, 9 lbs, 20.5″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • AUX05S (5 Gal, Steel, 17 lbs, 21.4″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • AUX10A (10 Gal, Aluminum, 13 lbs, 19.5″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • AUX10S (10 Gal, Steel, 28 lbs, 19.3″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • AUX20S (20 Gal, Steel, 42 lbs, 27″ Long, 125 PSI, Dual Air Fittings, Manual Drain Valve, 48″ Air Hose / Tire Chuck)
    • 60000-T (60 Gal, Replacement Steel ASME Vertical Air Receiver, 163 lbs, 56.5″ Height, 180 PSI)

    Refrigerated Air Dryers

    • RD-91503 (High-Efficiency Non-Recycling 98% Refrigerated Air Dryer, 220v 60hz)
    • RD-91502 (High-Efficiency Non-Recycling 98% Refrigerated Air Dryer, 110v 60hz)

    Automatic Drain Valve Kits

    • EZ2321ADL (Automatic Drain Valve Long Extension Kit, 110v 60hz)
    • EZ2321ADS (Automatic Drain Valve Short Extension Kit, 110v 60hz)

    Business Volume Discounts (B2B)

    • 1P1060S-4P — 1P1060S 4-Pack Bundle (1 Gal, 0.6 Hp, 1.2 CFM @90 PSI, Steel, 56dB noise level, 110v)
    • 2010A-4P — 2010A 4-Pack Bundle (2.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, 60dB noise level, 110v)
    • 4610S-4P — 4610S 4-Pack Bundle (4.6 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Steel, 60dB noise level, 110v)
    • 4610AC-4P — 4610AC 4-Pack Bundle (4.6 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, 60dB noise level, 110v)
    • 8010A-4P — 8010A 4-Pack Bundle (8.0 Gal, 1.0 Hp, 2.2 CFM @90 PSI, Aluminum Tank, Wheels, 60dB, 110v)
    • 4620AC-4P — 4620AC 4-Pack Bundle (4.6 Gal, 2.0 Hp, 5.3 CFM @90 PSI, Aluminum Tank, 70dB noise level, 110v)

    Live in Southern California? – Visit our Factory and get a deep discount on New or Reconditioned Models

    Southern California Factory Outlet (New & Reconditioned) – Local San Diego Pickup Only

    Model Nomenclature Definitions:

    • C = Condor Switch Feature
    • A = Aluminum Tank
    • AC = Aluminum Tank
    • S = Steel Tank
    • SP = Steel Tank + Front Panel
    • AD = Includes Automatic Drain Valve
    • CAD = Condor Switch + Automatic Drain Valve
    • SMAD = SMART Controller + Automatic Drain Valve
    • HP = High Pressure
    • DC = 80% Air Dryer
    • LFC = Steel Tank + Long Life Motor (i.e. 4000+ motor running hours)
    • ALFC = Aluminum Tank + Long Life Motor (i.e. 4000+ motor running hours)
    • LFDC = 80% Air Dryer & Long Life Motor (i.e. 4000+ motor running hours)
    • DCAD = 80% Air Dryer & Automatic Drain Valve
    • DSMAD = 80% Air Dryer + SMART Controller + Automatic Drain Valve
    • DCADC = 98% Air Dryer & Automatic Drain Valve
    • DSMADC = 98% Air Dryer + SMART Controller + Automatic Drain Valve
    • DCC = 98% Air Dryer, Twin-Tower Auto Purge
    • HDCADC = Horizontal Tank, 98% Air Dryer & Automatic Drain Valve
    • SPC = Standard Air Compressor in Sound Proof Cabinet
    • DSPC = 80% Dry Air Compressor in Sound Proof Cabinet
    • DSPCAD = 80% Dry Air Compressor in Sound Proof Cabinet & Automatic Drain Valve
    • DSPCADC = 98% Dry Air Compressor in Sound Proof Cabinet & Automatic Drain Valve
    • CR = Continuous Run Air Compressor (100% Duty Cycle)
    • BD = Belt Driven, Oiled Air Compressor (100% Duty Cycle)
    California Air Tools Marketing Product Line Card – Aug 2026Download
    Common Questions & AnswersDownload

    70/30 Duty Cycle vs. Continuous Operations (standard workday)

    All Oil-Free Air Compressor models are rated for 70/30 Duty Cycle (i.e. intermittent usage): Click Here For More Information – refer to Section 9. For continuous air volume operations during standard workday:

    • 1 hp models: your equip. requires 0.3-1 cfm (9-25 liters per minute, l/min) 90 PSI
    • 2 hp models: your equip. requires 0.5-2 cfm (10-55 l/min) 90 PSI*
    • 4 hp models: your equip. requires 2-4 cfm (56-110 l/min) 90 PSI**
    • 6 hp models: your equip. requires 4-7 cfm (112-180 l/min) 90 PSI

    *NOTE 1: 2.0 HP models cannot maintain 100 PSI (or higher) continuously for any longer than 5-10 minutes; 4.0 Hp models and above are only suggested.

    **NOTE 2: 4 Hp compressor models may run 2.0 to 4.2 cfm continuously (55-118 l/min) @90 PSI during a standard workday. 4 Hp models can generally run ~9-10 cfm @90 PSI for about 45-55 minutes maximum but will then need to stop hard for 15-20 minutes to allow motor/pumps to cool off….or….may run up to ~4 cfm @90 PSI for up to 4 hours at a time, with 15-20 stop break. If a 4 Hp 80% or 98% Dry Air model run beyond these conditions then excessive water build-up could result. Actual results may vary depending on environmental/installation space rH (relative Humidity); humidity levels greater than 75 rH can generate even higher output moisture content. Use of a dehumidifier is suggested to help control any observed moisture content issues.

    ***NOTE 3: 6 Hp compressor models may run 4-7 cfm (112-180 l/min) @90 PSI during a standard workday. 6 Hp models can generally run ~12-14 cfm @90 PSI for about 50 minutes maximum but will then need to stop hard for 15-20 minutes to allow motor/pumps to cool off….or….may run up to ~7.5 cfm @90 PSI for up to 4 hours at a time, with 15-20 stop break.

    California Air Tools Air Compressors Serve the following sectors and industries:

    • Homeowners
    • DIYers
    • Hobbyists
    • Engraving
    • Laser
    • Welding
    • Spray Painting
    • Air Brushing
    • Commercial Fire Protection
    • Aerospace
    • Hospital
    • Hygiene
    • Bar & Restaurant
    • Warehouse
    • Food & Beverage
    • Biotech
    • Dental Implants
    • Landscaping
    • Theme Parks
    • Information Management
    • Automotive & Autobody
    • Agriculture
    • Dental Office
    • Medical Sterilizing Systems
    • Dental Milling
    • Energy Equipment
    • Barber Shop
    • Skin Products
    • Gaming Systems
    • Integrated Solutions
    • Musical Instrument Repair
    • Plumbing/Construction
    • Roadside Service
    • Mobile & Stationary Detailing
    • Research and Development
    • Bio Reactors
    • Dental Labs
    • Education
    • Electric Vehicles
    • General Contractor
    • Jewelry & Rings
    • Craft Botanical Extractor
    • Cannabis
    • Dental Implants
    • Beer & Winery
    • Defense & Drone Manufacturing
    • Research and Development
    • Robotics
    • Engineering Pneumatics
    • Electronic Manufacturing
    • Furniture Manufacturing
    • Textiles & Clothing Manufacturing
    • Assembly & Packaging

    —

    CUSTOMER TESTIMONIALS

    Factory Outlet Website – New, Blemished and Used Items Available
    California Air Tools eBAY Site – Blemished and Used Items Available (small models only)

    Warranty & Customer Return Policy for items purchased:

    Warranty: 1 Year Manufacturer Limited Warranty.

    Return Policy: No Returns.

    Exchanges: 60 Day Exchange From Date of Purchase.

    Refunds: When approved, typically take 2 days.

    —-

    Shipping

    USA & CANADA
    Standard FedEx Parcel Ground or Estes Trucking LTL (on pallet) to locations in the Contiguous United States. Canada orders will be accepted if order total is over $2000 USD.

    No Direct Shipping to Alaska/Hawaii, US Protectorates, APO/FPO/DPO, PO Boxes or Outside USA, with the exception of approved Canada orders over $2000 USD. We do not ship to Asia, Europe, Australia or Africa.

    Hawaii CUSTOMERS
    You may purchase any item via our Factory Outlet Store and ship to Triple B Forwarders in Los Angeles, they will ship to HI (you will need to pay the transport over the water). California Air Tools can also provide a shipping quote upon request. Click here for details.

    OTHER REGIONS: You may purchase direct and we will ship to a Freight Forwarder located in the USA, then you may arrange transportation to your region. Contact us for more information: info@californiaairtools.com

    Items Will Be Shipped Between 1-3 Days (business days) of Order Date. Build-To-Order items may take up to an additional 4-5 days. Items are shipped from San Diego, CA and are typically received within 3 and 10 days depending on ship-to location, item size and carrier type.
